Asymmetric cycler mode - blink at the beginning of the pulse, blink at the beginning of the pause.

Time Relay - Cyclic Relay / Blinker (symmetrical / asymmetrical cycle)

Product Description

The cyclic time relay is designed for periodic switching on and off of electrical loads, such as lighting, fans, pumps, or alarm devices. It allows for independent setting of pulse and pause durations and operation in symmetrical or asymmetrical mode. It is suitable for control automation, ventilation, timed lighting or advertising.

Key Features

• Cyclic operation with adjustable ON and pause times

• Blinker mode: pulse at the beginning or pause at the beginning

• Symmetrical/asymmetrical duty cycle

• Switchable output contact

• Ability to start the cycle with a pulse or a pause

• Stable operation for automatic system control

• Mounting on 35 mm DIN rail

Applications

• Regular room ventilation

• Cyclic moisture drying

• Control of advertising lighting, flashing signs

• Control of circulation pumps

• Periodic switching of ventilation or heating

• Emergency light or sound signal

• Gradual switching on of electrical equipment when power is reduced

Advantages

• Easy time setting

• Versatility of use

• Safe and reliable control of electrical circuits

• Suitable for domestic and industrial control cabinets

Installation

• Installation on a standard 35 mm DIN rail
